ELP 720p HD USB Camera Module with Microphone H.264 Mini UVC USB2.0 Audio Video Webcam Board for Android Linux Windows Mac Video Surveillance PC Camera for Computer, Laptop, Raspberry Pi, Jetson Nano

Amazon.com Price: $18.99 (as of 01/11/2024 04:55 PST- Details) & FREE Shipping.

720P megapixel HD Resolution for high quality image and low power
H.264 compression technology on USB Camera for sharp image and accurate color
Can support microphone&IR Cut for low light or night image vision optional

Category:

Description

The 720P HD H.264 USB2.0 USB Camera module is ideal for house security and also many applications
like security systems, portable video system, video phones, industrial machine monitoring and toys.
It adopts high quality image sensors made by OV , one of the world leaders in this field of electronics.

It uses H.264 compression technology to reach high frame rate video output, and also YUY2 and MJPEG optional.

Application:
Car and ship control, electrical equipment, oil field equipment, industrial equipment, remote site monitoring,
environmental monitoring, Video Conferencing ,car tracking system, etc.

Feature:
1.720P sensor for high quality image and low power
2.Active pixel technology for sharp image and accurate color
3.Superior low light performance – ideal for any lighting
4.Super small outline and thin profile for embedded
5.High frame rate- deliver 30 fps in 720P
6.High quality lens for true to life undistorted color image
7.Bus powered with low power consumption – ideal for portable
8.Support OS “WinXP/Vista/WIN7/WIN8/Linux with UVC/Mac-OS X 10.4.8 or later/Wince with UVC/Android 4.0 or above”

Parameters:
Sensor:OV9712
Picture format “H.264, YUY2 and MJPEG optional”/USB Protocal USB2.0 HS/FS
Auto exposure AEC Support/Auto white blance AEB Support
Performance:
1280 (H) x 720 (V): H.264 30fps/MJPEG 30fps/YUY2 10fps
800 (H) x 600 (V): H.264 30fps/MJPEG 30fps/YUY2 20fps
640 (H) x 480 (V): H.264 30fps/MJPEG 30fps/YUY2 30fps
Adjustable parameters Brightness/Contrast/Color saturation /Definition/Gamma/WB
Night vision optional, can support IR Cut and IR board for IR night vision(this function is optional).
720P megapixel HD Resolution for high quality image and low power
H.264 compression technology on USB Camera for sharp image and accurate color
Can support microphone&IR Cut for low light or night image vision optional
Super small outline and thin profile for embedded
High frame rate- deliver 30 fps in 720P for real time video view at house or inside device
